Technical | Data |
Duty Cycle | 60% |
Current | 105Amp/125Amp |
Gas | Air/N2 |
Gas Pressure | 5.0-5.5 Bar |
Gas Flow | 255 LPM |
lgnition | Without HF |
Post Flow | 120 sec.recommended |
Standard Length | 6M |
Complete Torch
Code | Ref | Description |
JWU03252 | Plasma Cutting Torch/ PMX105/ 6m/ 1/4 G/ integrated / 2 wires | |
JWU03253 | Plasma Cutting Torch/ PMX105/ 6m/ 1/4 G/ separate / 2 wires | |
JWU03254 | Plasma cutting torch/ PMX105/ 6m/ central adaptor/ 2 wires | |
JWU032441 | Plasma cutting torch/ PMX105/ 6m/ central adaptor/ 4 wires | |
JWU03255 | Plasma cutting torch/ PMX105/ 6m/ central adaptor/ coaxial cable | |
JWU03252-01 | Plasma Cutting Torch/ PMX105P/ 6m/ 1/4 G/ integrated / 2 wires | |
JWU03253-01 | Plasma Cutting Torch/ PMX105P/ 6m/ 1/4 G/ separate / 2 wires | |
JWU03254-01 | Plasma cutting torch/ PMX105P/ 6m/ central adaptor/ 2 wires | |
JWU032441-01 | Plasma cutting torch/ PMX105P/ 6m/ central adaptor/ 4 wires | |
JWU03255-01 | Plasma cutting torch/ PMX105P/ 6m/ central adaptor/ coaxial cable |
Position | Code | Ref. | Description |
1 | Shield cap; 保护帽 | ||
1.1 | 220818 | Shield cap/45A-85A/; 保护帽/45A-85A | |
1.2 | 220993 | Shield cap 105A; 保护帽/105A | |
2 | 220798 | Shield cap/Gouging; 保护帽/气刨 | |
3 | Tip; 喷嘴 | ||
3.1 | JTN0634 | Shield cap PMX65/85/hand/45A-85A/PRO; 保护帽PMX65/85/手动枪/45A-85A/PRO | |
3.2 | JTN0632 | Shield cap /PMX105/Hand/105A/PRO; 保护帽/PMX105/手动枪/105A/Pro | |
4 | Shield cap; 保护帽 | ||
4.1 | JTN0604 | Shield cap /PMX1000/1250/1650/hand/40A-80A; 保护帽/PMX1000/1250/1650/手动/40A-80A | |
4.2 | JTN0605 | Shield cap /PMX1000/1250/1650/machine/40A-80A; 保护帽/PMX1000/1250/1650/自动/40A-80A | |
5 | Tip; 喷嘴 | ||
5.1 | 220941 | Tip/45A; 喷嘴 45A | |
5.2 | 220819 | Tip/65A; 喷嘴 65A | |
5.3 | 220816 | Tip/85A; 喷嘴 85A | |
5.4 | 220990 | Tip/105A; 喷嘴 105A | |
6 | Tip; 喷嘴 | ||
6.1 | 220797 | Tip /45A-85A/Gouging; 喷嘴 45A-85A/气刨 | |
6.2 | 220991 | Tip /105A/Gouging; 喷嘴 105A/气刨 | |
7 | Tip ; 喷嘴 | ||
7.1 | JWV0664-09 | Tip Φ0.9mm/PMX65/45A/PRO; 喷嘴 Φ0.9mm/PMX65/45A/PRO | |
7.2 | JWV0664-11 | Tip Φ1.1mm/PMX65/65A/PRO; 喷嘴 Φ1.1mm/PMX65/65A/PRO | |
7.3 | JWV0664-13 | Tip Φ1.3mm/PMX65/65A/PRO; 喷嘴 Φ1.3mm/PMX65/65A/PRO | |
7.4 | JWV0664-15 | Tip Φ1.5mm/PMX65/65A/PRO; 喷嘴 Φ1.5mm/PMX65/65A/PRO | |
7.5 | JWV0664-18 | Tip Φ1.3mm/PMX105/125A/PRO; 喷嘴 Φ1.3mm/PMX105/125A/PRO | |
8 | JWG3003 | Swirl ring PMX105/105A; 涡流环 PMX105/105A | |
9 | 220842 | Electrode; 电极 | |
10 | JWC0043 | Electrode PMX65/85/105/43.4; 电极PMX65/85/105/43.4 | |
11 | JWA0662 | Plasma torch head/PMX65/85/105/M; 等离子自动枪头/PMX65/85/105 | |
11a | JGU0686 | O RING Φ17*20.6*1.8 /Red silicone/; O型圈Φ17*20.6*1.8/红色硅胶 | |
| 12 | JHW0046-01 | Plasma handle manual/A series/red;等离子手工手柄/A系列/红色/高频低频共用 | |
| 13 | JIK0733 | Protection part/plasma/yellow; 开关保护档片/等离子用/黄色 | |
| 14 | JIR0081 | Trigger red; 焊枪用开关 21.8MM 红色 | |
| 15 | JIK0804 | Tig joint/small/new type; TIG用球节套件/小/新式 | |
| 16 | Cable assembly; 电缆组 | ||
| 16.1 | JWO02010072-300 | Cable assembely/PMX85/105/6M/2 wires/separated; 电缆组/PMX85/105/6M/两芯控制线/气电分体 | |
| 16.2 | JWO02010074-300 | Cable assembely/PMX85/105/6M/2 wires/integrated; 电缆组/PMX85/105/6M/两芯控制线/气电一体 | |
| 16.3 | JWO02010071-300 | Cable assembely/PMX85/105/6M/2 wires/centre adapter; 电缆组/PMX85/105/6M/两芯控制线/中央插头 | |
| 16.4 | JWO02010077-300 | Cable assembely/PMX85/105/6M/4 wires/centre adapter; 电缆组/PMX85/105/6M/四芯控制线/中央插头 | |
| 16.5 | JWO0201017C-300 | Cable assembely/PMX85/105/6M/coaxial cable/centre adapter; 电缆组/PMX85/105/6M/同轴电缆/中央插头 | |
| 17 | JAY0089 | Centre adaptor torchside PLASMA 5 PINS; 等离子中央插头/5针 | |
